3-Phase AC Induction Motor YDQ5-4-5685

10 teeth spline, speed sensor, temperature sensor

Speed Sensor

YDQ5-4-5685 is a Low Voltage AC (LVAC) Induction Motor.

Low voltage AC (LVAC) induction motors are the workhorse motor technology for many segments of the electric vehicle industry; providing a tough-to-beat balance of cost, performance, efficiency, reliability, mechanical simplicity, motor control simplicity and overall system cost.

AC induction motors are one of the simplest motor mechanical constructions available. They offer both a balanced 3-phase wound stator and cast rotor core. LVAC motors transfer electrical energy from stator to rotor without slip rings or brushes, making for smooth, quiet and reliable operation. Motors are designed to be maintenance-free for life with no wear parts or service items. The specify highly reliable temperature and speed sensors are available to provide dynamic data to the motor control.

Used as traction motor of golf carts and variable electric vehicles, YDQ5-4-5685 is suitable as the replacement of multiple AC motor models of Club Car & EZGO golf carts (with 10-teeth spline).

Specifications:

• Model: YDQ5-4-5685
• Motor type: 3-phase AC induction motor
• Spline: 10-teeth EQS
• Nominal power rate: 5.0 kW
• Nominal voltage: 33V
• Current: 110A
• Duty: S2-60min
• Speed: 3336 rpm
• Speed sensor & temperature sensor mating connectors is included
• Insulation: Class H
• Weight: 29.9 kg (package weight: 32 kg)

Motor Diagram:
